427 Cobra




Package #1 - 427 Cobra Roadster - Chassis & Superstructure Drawings



Price: $600

This set of drawings provides exacting fabrication details for the chassis of my original 427 Roadster Cobra. The package presently includes over 62 drawings including over 120 individual parts and assembly views detailing the fabrication for all major chassis tubes and brackets. Chassis top, side and end views are provided showing the assembly of the individual pieces to create the complete chassis.

Refer to the Index and Notes drawing below for details (click anywhere on the drawing to open a larger scale PDF version.)


Package #2 - 427 Cobra Roadster - Miscellaneous Information package



Price: PRICE AND DETAILS COMING SOON
